IEK

ARMAT circuit breaker M06N 2P B 32A IEK AR-M06N-2-B032

SKU: AR-M06N-2-B032

ETIM: EC000042

1990 ₽

Price list (incl. VAT): 2654 ₽

Available August 17

	Warehouse	Qty	Unit	Ready for pickup	Delivery to Смоленск
	Склад производителя Available	5	шт	August 17	August 17

Select a warehouse to order

Description Specifications Reviews

Weight per pole	0,116
Additional equipment possible
Busbar connection capability	PIN (pin), FORK (fork)
Release response time in short-circuit range tm	0,1
Electric shock protection class	0
Current limiting class
Number of protected poles	2
Number of poles
Number of power poles	2
Maximum supply cable cross-section	25 кв.мм
Mech. endurance	20000
Explosion protection present	Without explosion protection
Availability of residual current release	No
Thermal release available	Yes
Electromagnetic release present	Yes
Electronic release available	No
Rated impulse withstand voltage	6
Rated short-circuit breaking capacity Icu IEC 60898 at 230 V	6 кА
Rated short-circuit breaking capacity Icu IEC 60898 at 400 V	6 кА
Rated breaking capacity in accordance with EN 60898	кА
Rated voltage	400 В
Rated insulation voltage Ui	500 В
Rated current	32 А
Total number of poles	2
Power loss	12.0 Вт
Ambient operating temperature to	70 град.C
Ambient operating temperature from	-40 град.C
Operating mode	Continuous-S1
Repairability	No
Current type	Alternating current (AC)
With switched neutral conductor	No
Tripping system	Thermal, electromagnetic
Mounting method	On DIN rail
IP protection rating	IP20
Application area	Domestic
Mounting rail type	35x7.5
Connection type
Tripping characteristic	B
Frequency	50 Гц
Frequency at	50 Гц
Frequency from	50 Гц
Width in modular units	2
Electrical endurance	10000
