IEK

ARMAT Автоматический выключатель M06N-DC 3P L 4А IEK AR-M06N-3-L004DC

SKU: AR-M06N-3-L004DC

ETIM: EC000042

11003 ₽

Price list (incl. VAT): 14671 ₽

Preorder

Description Specifications Reviews

Weight per pole	0,00012
Additional equipment possible
Busbar connection capability	PIN (pin), FORK (fork)
Electric shock protection class	0
Current limiting class
Climatic version	UKhL3
Number of protected poles	3
Number of poles
Maximum supply cable cross-section	25 кв.мм
Mech. endurance	20000
Explosion protection present	Without explosion protection
Availability of residual current release	No
Thermal release available	Yes
Electromagnetic release present	Yes
Rated impulse withstand voltage	6
Rated short-circuit breaking capacity Icu IEC 60898 at 230 V	6 кА
Rated short-circuit breaking capacity Icu IEC 60898 at 400 V	6 кА
Rated breaking capacity in accordance with EN 60898	кА
Rated impulse voltage	6 кВ
Rated voltage	750 В
Rated insulation voltage Ui	1000 В
Rated DC voltage from	750 В
Rated current	4 А
Total number of poles	3
Ambient operating temperature to	40 град.C
Ambient operating temperature from	-5 град.C
Operating mode	Continuous-S1
Repairability	No
Current type	Direct current (DC)
Switch-on current type	Constant (DC)
With time delay	No
With switched neutral conductor	No
Stranded flexible conductor cross-section from	25 кв.мм
Solid conductor cross-section from	25 кв.мм
Tripping system	Thermal, electromagnetic
Mounting method	On DIN rail
Pollution degree (number)	2
IP protection rating	IP20
Application area	Industrial and domestic
Mounting rail type	TN-35
Connection type
Tripping characteristic	Other
Frequency from	- Гц
Width in modular units	54
Electrical endurance	6000
