ARMAT Контактор КМИ-АL-11812 LC1D 18А 230В/АС3 1NO/1NC IEK AR-ACC-11-018-230-11-L

SKU: AR-ACC-11-018-230-11-L

ETIM: EC000066

4493 ₽

Price list (incl. VAT): 7189 ₽

Preorder

Кратность заказа: 50

Description Specifications Reviews

Weight	0.34 кг
Manual control capability	No
Height	мм
Flexible cable without ferrule
Control voltage ranges at release Uc	0.3...0.6
Control voltage ranges at operation Uc	0.8...1.1
Aux. contact - overcurrent protection - gG fuse	10
Aux. contact - Max. short-time load	100
Auxiliary contacts - minimum making capacity Imin
Aux. contact - minimum making capacity Umin
Aux. contact - rated voltage Un AC
Aux cont - rated insulation voltage Ui
Aux. contact - insulation resistance
Add. contact - thermal current In	10
Rigid cable without ferrule
Overcurrent protection - gG fuse	50
Number of additional contacts
Number of auxiliary NO contacts	1
Number of auxiliary NO contacts, main	0
Number of auxiliary changeover contacts	2
Number of auxiliary break contacts	1
Number of time-delayed auxiliary NC contacts	0
Number of poles	3
Switching durability at AC-1
Max. short-time load
Mech. endurance
Mechanical wear resistance
Tightening torque from	2.5 Н·м
Power dissipation at Ie AC-1
Rated AC operating voltage Ue
Rated impulse voltage	6 кВ
Rated insulation voltage Ui	690 В
Rated control supply voltage Us AC at 50 Hz from	230 В
Rated operational current Ie, 400 V	18 А
Switch-on current type	Alternating current (AC)
With LED display	No
Mounting method	DIN rail / screw
IP protection rating	IP20
Operating temperature from	град.C
Auxiliary circuit connection type	Screw connection
Conventional thermal current Ith at AC-1
Conditional short-circuit current Inc	3000
Width	45.0 мм
