Residual current circuit breaker with overcurrent protection AD-2 2P (S) 50A curve C 100mA type AC electronic selective 6kA PROXIMA EKF DA2-6-50-100S-pro
SKU: DA2-6-50-100S-pro
ETIM: EC000905
1530 ₽
Price list (incl. VAT):
2489 ₽
Available August 3
Availability
| Warehouse | Qty | Unit | Ready for pickup | Delivery to Smolensk | |
|---|---|---|---|---|---|
|
Transit warehouse
Available
|
1 | шт | August 3 | August 3 |
Select a warehouse to order
The AD-2(4) (S) EKF PROxima residual current circuit breaker (RCBO) is a device that combines the functions of a circuit breaker with a residual current device. When the circuit breaker detects a leakage current (fault) to ground or an overcurrent (overload or short circuit) in the protected network section, the device trips, leading to the disconnection of the protected network. A special feature of EKF residual current breakers is the presence of a built-in surge protection unit. AD-2 and AD-4 EKF PROxima are available in standard and selective (AD-2S, AD-4S) versions.
| Mounting installation depth | 74 мм |
| For flush mounting | Yes |
| False tripping protection | No |
| Overvoltage category | 3 |
| Current limiting class | 3 |
| Number of protected poles | 2 |
| Rated breaking capacity in accordance with EN 60898 | 6 кА |
| Rated breaking capacity per IEC 60947-2 | 6 кА |
| Rated short-circuit breaking capacity Icn per EN 61009-1 | 6 кА |
| Rated impulse voltage | 6 кВ |
| Rated voltage | 230 В |
| Rated insulation voltage Ui | 500 В |
| Rated current | 50 А |
| Rated leakage current | 0.1 мА |
| Total number of poles | 2 |
| Ambient operating temperature to | 50 град.C |
| Ambient operating temperature from | -25...50 град.C |
| Current type | AC (alternating) |
| With switched neutral conductor | Yes |
| With interlock device | No |
| Flexible stranded conductor cross-section up to | 16 кв.мм |
| Stranded flexible conductor cross-section from | 0...16 кв.мм |
| Solid conductor cross-section to | 25 кв.мм |
| Solid conductor cross-section from | 0...25 кв.мм |
| Pollution degree (number) | 3 |
| IP protection rating | IP20 |
| Residual current type | AC (alternating) |
| Resistance to current surges | 6 кА |
| Tripping characteristic | Without delay |
| Tripping characteristic | It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly. |
| Frequency (Hz) | 50/60 Hz |
| Width in modular units | 3 |
