Generica (Группа IEK)
Residual current circuit breaker AD12 2P 32A 30mA GENERICA MAD15-2-032-C-030
SKU: MAD15-2-032-C-030
ETIM: EC000905
1464 ₽
Preorder
Быстродействующие защитные выключатели обеспечивают:
– в исполнениях с уставкой срабатывания 30 мА – защиту людей от поражения электрическим током при прямом непреднамеренном прикосновении к токоведущим частям электрооборудования.
– защиту от перегрузки и короткого замыкания.
| Mounting installation depth | 75 мм |
| Current limiting class | |
| Number of protected poles | 2 |
| Number of poles | |
| Maximum supply cable cross-section | 25 кв.мм |
| Availability of residual current release | Yes |
| Thermal release available | Yes |
| Electromagnetic release present | Yes |
| Electronic release available | No |
| Rated impulse withstand voltage | 4 |
| Rated differential making and breaking capacity | 4500 |
| Rated breaking capacity in accordance with EN 60898 | 4.5 кА |
| Rated breaking capacity per IEC 60947-2 | 4.5 кА |
| Rated voltage | 230 В |
| Rated current | 32 А |
| Rated leakage current | .03 мА |
| Total number of poles | 2 |
| Breaking capacity per IEC 61009-1 | 4500 |
| Breaking capacity | 4.5 кА |
| Current type | Alternating current (AC) |
| With switched neutral conductor | Yes |
| Tripping system | Thermal, electromagnetic |
| Mounting method | On DIN rail |
| IP protection rating | IP20 |
| Residual current type | Alternating current (AC) |
| Connection type | |
| Tripping characteristic | C |
| Frequency (Hz) | 50 Hz |
| Width in modular units | 3.4 |
