IEK
Vertical internal tray angle 45deg. 80x400 2mm HDZ ESCA 7 IEK ES7-PN-45-080-400-20-HDZ
SKU: ES7-PN-45-080-400-20-HDZ
ETIM: EC002400
9835 ₽
Price list (incl. VAT):
15736 ₽
Preorder
Vertical internal 45° bend is designed for organizing cable route turns in the vertical plane.
The accessory is joined to the tray using a telescopic connector.
Suitable for all types of ESCA series sheet metal trays.
The cover for the accessory is ordered separately.
The accessory is made of hot-dip galvanized steel (zinc protective layer not less than 55 μm).
| Weight | 2.96 кг |
| Material type/grade | Other |
| Height | 80 мм |
| Height | 80 мм |
| Cable tray height | 80 мм |
| Length | 316 мм |
| Length | 316 мм |
| Protective surface coating | Hot-dip coating |
| Direction change | Vertically ascending (internal) |
| Design | Integrated connector |
| Corrosion resistance class | 6 |
| Climatic version | U1, KhL1, UKhL1, UKhL5, OM1 |
| Material | Steel |
| Mounting perforation in base | No |
| Mounting temperature from | -50...40 град.C |
| Pickled stainless steel | No |
| RAL colour number | 7047 |
| Perforated side wall | No |
| Rotation (angle) | 45 |
| Suitable for circuit integrity (fire resistance) | No |
| IP protection rating | IP00 |
| Operating temperature from | -50...40 град.C |
| Metal thickness | 2.0 |
| Zinc coating thickness | 55 |
| Colour | Light grey |
| Color | Light grey |
| Width | 400 мм |
| Cable tray width | 400 мм |
| Branch width | 400 мм |
| Wide-range version | No |
