Insulated phase sleeve GIF 25 (MJPT 25) IEK UZA-23-D25
SKU: UZA-23-D25
ETIM: EC001060
277 ₽
Price list (incl. VAT):
370 ₽
Available August 20
Order multiple: 10
Availability
| Warehouse | Qty | Unit | Ready for pickup | Delivery to Smolensk | |
|---|---|---|---|---|---|
|
Manufacturer warehouse
Available
|
390 | шт | August 20 | August 20 |
Select a warehouse to order
GIF sleeves for messenger neutral wires serve for mechanical and electrical connection of phase wires in SIP systems with a messenger neutral. Applicable for aluminum multi-strand wires; a specific wire cross-section corresponds to a specific color of the sealing ring. The internal cavity of the aluminum part is filled with contact grease, which protects the aluminum surface from oxidation and reduces contact resistance, leading to a significant reduction in energy losses. The insulation material is a polymer resistant to ultraviolet radiation and climatic conditions. For messenger wires, the allowable mechanical loads on the crimped connection are 60% of the strength of the messenger neutral.
| Weight | 0.05 кг |
| Outer diameter | 22.0 мм |
| Internal diameter 1 | 6.5 |
| Inner diameter 2 | 6.5 |
| Operating temperature range | -50...+60 |
| Length | 98.0 мм |
| Length | 98.0 мм |
| For strain-relieved connections | Yes |
| Material | Aluminum |
| Nominal cross-section of aluminum cores | 25 кв.мм |
| Suitable for aluminium-magnesium cables | No |
| Application | For main phase conductors |
| Voltage range | Up to 1 kV |
| Left-side SIP cross-section | 25.0 |
| Right-side SIP cross-section | 25.0 |
| Die type for sleeve crimping | E173 |
| Reduced rated cross-section - aluminum | Please provide the text you would like me to translate. мм² |
| Cross-section shape | Stranded round/sector conductor |
| Left sealing ring color | Orange |
| Right sealing ring colour | Orange |
