LAPP
FLEXICORE LiYY (TP) 10x2x0.14 (m) LAPP 3120002217
SKU: 3120002217
ETIM: EC000104
224 ₽
Preorder
FLEXICORE® TP – низкочастотные кабели управления с парной скруткой жил с изоляцией и оболочкой из ПВХ с номинальным рабочим напряжением до 60 В, максимальное пиковое рабочее напряжение - 350 В для кабелей с сечением 0,14 мм2, 500 В для кабелей с сечение от 0,25 мм2 и выше (не для силовых цепей) .
| Permissible operating temperature (no movement) to | -60 град.C |
| Permissible operating temperature (without movement) from | 70 град.C |
| Protective grounding conductor | No |
| Core insulation | Polyvinyl chloride (PVC) |
| Conductor class | 5 - flexible stranded |
| Number of cores | 20 |
| Core marking | Colour |
| Oil resistance in accordance with EN 60811-2-1 | Yes |
| Outer sheath material | Polyvinyl chloride (PVC) |
| Outer diameter (approx.) | 9.3 мм |
| Rated voltage U | 60 кВ |
| Rated conductor cross-section | .14 кв.мм |
| Fire resistance | In accordance with EN 60332-3-22 |
| Recommended installation temperature during pulling, up to | 80 град.C |
| Recommended installation temperature during pulling from | -20 град.C |
| Low temperature resistance in accordance with EN 60811-1-4 | No |
| Outer sheath colour | Grey |
