DKC
Feed-through terminal, bolt clamp, 2 connection points, 70 sq.mm, gray FER-70 DKC
SKU: FER-70
ETIM: EC000897
1538 ₽
Price list (incl. VAT):
2197 ₽
Available July 29
Availability
| Warehouse | Qty | Unit | Ready for pickup | Delivery to Смоленск | |
|---|---|---|---|---|---|
|
Удалённый склад
|
4 | шт | July 29 | July 29 |
Select a warehouse to order
Клемма проходная с болтовым зажимом предназначена для коммутации 2 проводников. Монтаж на DIN-рейку OMEGA или панель. Температура эксплуатации от -40 до +105°C. Корпус выполнен из ПА 6.6 с классом горючести V0 UL-94.
Серый цвет, 2 точки подключения, 70 мм2. Монтаж перемычек на шпильку клеммы. Габариты (В?Ш?Г) 64?132?32 мм.
| Version tested for explosion protection "Ex e" | No |
| Internally linked levels | No |
| Minimum possible mounting height | 64 мм |
| Length | 132 мм |
| Length | 132 мм |
| Flammability class of insulation material in accordance with UL57 | V0 |
| Number of terminals per level | 2 |
| Number of poles | 2 |
| Number of levels | 1 |
| Housing insulation material | Thermoplastic |
| Rated voltage | 1000 В |
| Rated current In | 192 А |
| Closing plate can be fitted if required | No |
| Operating temperature | 105 град.C |
| Operating temperature from | -40 град.C |
| Connection position | Side |
| Core cross-section | 70 кв.мм |
| Stranded wire cross-section with ferrule | 2.5...90 мм² |
| Mounting method | DIN rail 35 mm |
| Electrical connection type 1 | Bolted connection |
| Electrical connection type 2 | Bolt connection |
| Color | Grey |
| Colour | Grey |
| Width/connection pitch | 32 мм |
