DKC

Feed-through terminal, push-in clamp, 2 connection points, 4 sq.mm, gray VPR-4-GY DKC

SKU: VPR-4-GY

ETIM: EC000897

111 ₽

Price list (incl. VAT): 111 ₽

Available July 30

	Warehouse	Qty	Unit	Ready for pickup	Delivery to Смоленск
	Удалённый склад	303	шт	July 30	July 30
	Склад производителя Available	24240	шт	July 31	July 31

Select a warehouse to order

Description Specifications Reviews

Version tested for explosion protection "Ex e"	No
Internally linked levels	No
Minimum possible mounting height	36.8 мм
Length	55.9 мм
Length	55.9 мм
Flammability class of insulation material in accordance with UL57	V0
Number of terminals per level	2
Number of poles	2
Number of levels	1
Housing insulation material	Thermoplastic
Rated voltage	800 В
Rated current In	32 А
Closing plate can be fitted if required	Yes
Operating temperature	105 град.C
Operating temperature from	-40 град.C
Connection position	Top
Core cross-section	4 кв.мм
Stranded wire cross-section with ferrule	0.2...4 мм²
Flexible stranded conductor cross-section up to	4 кв.мм
Stranded flexible conductor cross-section from	.14 кв.мм
Solid conductor cross-section to	6 кв.мм
Solid conductor cross-section from	.2 кв.мм
Extra-fine-stranded flexible conductor cross-section without ferrule, from	0.14...4 кв.мм
Mounting method	DIN rail 35 mm
Electrical connection type 1	Spring clamp connection
Electrical connection type 2	Spring clamp connection
Colour	Grey
Color	Grey
Width/connection pitch	6.2 мм
