DKC

Three-level terminal, push-in clamp, 6 connection points, 2.5 sq.mm, blue VPR-2.5-3L-BU DKC

SKU: VPR-2.5-3L-BU

ETIM: EC000897

402 ₽

Price list (incl. VAT): 574 ₽

Available July 30

	Warehouse	Qty	Unit	Ready for pickup	Delivery to Смоленск
	Склад производителя Available	4450	шт	July 30	July 30

Select a warehouse to order

Description Specifications Reviews

Version tested for explosion protection "Ex e"	No
Internally linked levels	No
Minimum possible mounting height	58.1 мм
Length	103 мм
Length	103 мм
Flammability class of insulation material in accordance with UL57	V0
Number of terminals per level	2
Number of poles	6
Number of levels	3
Housing insulation material	Thermoplastic
Rated voltage	500 В
Rated current In	24 А
Closing plate can be fitted if required	Yes
Operating temperature	105 град.C
Operating temperature from	-40 град.C
Connection position	Top
Core cross-section	2.5 кв.мм
Stranded wire cross-section with ferrule	0.14...2.5 мм²
Flexible stranded conductor cross-section up to	2.5 кв.мм
Stranded flexible conductor cross-section from	.14 кв.мм
Solid conductor cross-section to	4 кв.мм
Solid conductor cross-section from	.14 кв.мм
Extra-fine-stranded flexible conductor cross-section without ferrule, from	0.14...2.5 кв.мм
Mounting method	DIN rail 35 mm
Electrical connection type 1	Spring clamp connection
Electrical connection type 2	Spring clamp connection
Colour	Blue
Color	Blue
Width/connection pitch	5.2 мм
