EMAS
Signal column 50mm 24V LED alum. tube 100mm buzzer red. green. EMAS IK52L024ZM03
SKU: IK52L024ZM03
ETIM: EC001042
12,418 ₽
Get back 124 ₽ in points
Analogues by specifications
Signal column 50mm, 2 colors (red, green), with buzzer, LED, alum. tube 100mm with base, 24V AC/DC, IP40
TECHNICAL INFORMATION
Sound module (buzzer) 90dB
Lamp type LED
Operating frequency 50Hz
Operating voltage 24V AC/DC
Column diameter 50 mm
Power consumption 4W
Insulation voltage (Ui) 300V
Operating temperature -25 °C / + 70 °C
Protection class IP40
Cable connection cross-section 0.75-1.5mm2
Clamping force 1.8 N
Socket type BA15S
Series IK
Electrical life (min. hours) 10,000 hours
EMAS signal columns are used for visual and sound-visual signaling of equipment status, providing permissive or prohibitive light signals, and warning personnel of emergency and extraordinary situations related to safe equipment operation. The range includes signal columns with incandescent bulbs, LED lamps, and strobe LED lamps (flashing). Signal columns have a modular design, are installed without tools, and provide continuous information on current operating modes, presence of malfunctions, and possible critical states. The signal column can be equipped with an acoustic signaling device (buzzer) 90 dB.
Advantages of signal fittings:
• Heat-resistant
• Two types of outer diameter 50mm - 70mm
• Polycarbonate lens
• Convenient connection methods
• Various supply voltages
• Housing is resistant to mechanical impacts
• Buzzer option
