Cam Switch Standard Handle 10A Diagram 110 IEK MI-CS10-010-110

SKU: MI-CS10-010-110

ETIM: EC002611

1747 ₽

Price list (incl. VAT): 1986 ₽

Available August 20

Order multiple: 90

Availability

	Warehouse	Qty	Unit	Ready for pickup	Delivery to Smolensk
	Manufacturer warehouse Available	128	шт	August 20	August 20

Select a warehouse to order

Description Specifications Reviews

Design as auxiliary/maintenance switch	Yes
Version as main switch	Yes
Number of auxiliary NO contacts	0
Number of auxiliary break contacts	0
Number of switch positions	5
Number of poles	3
Complete device in housing	No
Design	Built-in device
Maximum rated operational voltage Ue AC	690 В
Mech. endurance	0.3
Modular design	Yes
Circuit diagram number	110
Rated impulse withstand voltage	4
Rated power at AC-2 230 V	2
Rated power at AC-2 400 V	3
Rated power at AC-23 230V	3
Rated power at AC-23 400 V	5
Rated power at AC-3 230 V	1
Rated power at AC-3 400 V	2
Rated power at AC-4 230V	0.37
Rated power at AC-4 400 V	0.55
Rated AC operating voltage of contacts	230; 400; 690
Nominal operating voltage of DC contacts	24; 48; 110; 220
Rated operational current Ie at AC-2 230 V	5.5
Rated operational current Ie at AC-2 400 V	5.5
Rated operational current Ie at AC-21 AC-22 230 V	10
Rated operating current Ie at AC-21 AC-22 400 V	10
Rated operational current Ie at AC-23 230 V	7.5
Rated operating current Ie at AC-23 400V	6.5
Rated operating current Ie at AC-3 230 V	1.75
Rated operating current Ie at AC-3 400V	1.75
Rated operating current Ie at AC-4 230 V	2
Rated operational current Ie at AC-4 400 V	2
Rated thermal current Ith	10
Rated conditional short-circuit current Icn	3
Rated connection capacity	2.5
Rated voltage	690 В
Rated insulation voltage Ui	690 В
Rated DC voltage from	24; 48; 110; 220 В
Rated continuous current Iu	10.0 А
Position designation	0-1-2-3-4-5
Suitable for front panel mounting	Yes
Suitable for base mounting	No
Suitable for intermediate mounting	Yes
Suitable for distribution board	No
Front panel size	48x48 mm
With control unit	No
With return to zero position	No
With zero position	Yes
Stranded flexible conductor cross-section from	1.5…4 кв.мм
Ingress protection (IP) of front side	IP40
Ingress protection (IP) in enclosure	IP40
Ingress protection (IP) - contact side	IP00
IP protection rating	IP20
Operating temperature from	-5…40 град.C
Switch type	Reversing
Switch type	Reversing
Product/component type	Cam switch
Design type	Open
Main electrical circuit connection type	Screw connection
Control element type	Short rotary handle (narrow grip)
Fuse current qG	12
Switch position latching	Yes
Switching function	Multi-step selector switch
Color	Black
Colour	Black
Electrical endurance	0.0015
