Frequency converter GD270-315-4-L3 315kW 380V built-in DC choke and output choke INVT 11001-02133

SKU: 11001-02133

ETIM: EC001857

836201 ₽

Preorder

Description Specifications Reviews

Height	1619 мм
Output power at rated output voltage	315 кВт
Depth	544 мм
Number of HW PROFINET interfaces	1
Number of HW USB interfaces	0
Number of HW serial RS-485 interfaces	1
Number of analog inputs	2 шт.
Number of analogue outputs	2 шт.
Number of input phases	3
Number of output phases	3
Number of digital inputs	6 шт.
Number of digital outputs	2 шт.
Maximum output power at linear load at rated output voltage	315 кВт
Maximum output frequency	400 Гц
Maximum output voltage	380 В
Mains voltage to	480 В
Mains voltage from	380 В
Rated output voltage	380 В
Rated output current	600 А
Rated output current	600 А
Relative symmetrical permissible mains frequency deviation	5 %
Relative symmetrical permissible mains voltage limit	10 %
MODBUS protocol support	Yes
PROFIBUS protocol support	Yes
PROFINET IO protocol support	Yes
Protocol support for other system buses	Yes
With control unit	Yes
With optical interface	No
With PC connection	Yes
IP protection rating	IP00
Mains frequency	50 Hz
Width	390 мм
