Frequency converter type PAC0200 Phd 37kW Ihd 75A Pn 45kW In 92A 400V IP20 PitON PAC0200X075AX3
SKU: PAC0200X075AX3
ETIM: EC001857
Price on request
Preorder
No description available
| Height | 555 мм |
| Depth | 325 мм |
| Number of HW PROFINET interfaces | 0 |
| Number of HW USB interfaces | 0 |
| Number of HW serial RS-485 interfaces | 1 |
| Number of analog inputs | 3 шт. |
| Number of analogue outputs | 2 шт. |
| Number of input phases | 3 |
| Number of output phases | 3 |
| Number of digital inputs | 9 шт. |
| Number of digital outputs | 2 шт. |
| Maximum output power at linear load at rated output voltage | 37 кВт |
| Maximum output frequency | 400 Гц |
| Mains voltage to | 440 В |
| Mains voltage from | 380 В |
| Rated output current | 92 А |
| Rated output current | 75 А |
| Relative symmetrical permissible mains frequency deviation | 5 % |
| Relative symmetrical permissible mains voltage limit | 15 % |
| MODBUS protocol support | Yes |
| PROFIBUS protocol support | No |
| PROFINET IO protocol support | No |
| Protocol support for other system buses | No |
| With PC connection | Yes |
| IP protection rating | IP20 |
| Mains frequency | 50 Hz |
| Width | 270 мм |
