PVI-13 delay on switch-on 0.1-3sec 1NO+1NC IEK KPV10-11-3
SKU: KPV10-11-3
ETIM: EC001043
1011 ₽
Price list (incl. VAT):
1617 ₽
Preorder
Приставки контактные ПКИ предназначены для расширения возможностей использования контакторов в системах автоматизации технологических проектов. Пневматические приставки выдержки времени ПВИ позволяют получить задержку замыкания или размыкания вспомогательной цепи от 0,1 до 180 с. Используются совместно с контакторами серии КМИ и КТИ.
| Weight | 0.08 кг |
| Height | 50.0 мм |
| Depth | 58.0 мм |
| Switch-on time delay range | 0,1...3,0 |
| Operating temperature range | -40...+50 |
| Climatic version | UKhL4 |
| Number of normally closed (NC) contacts | 1 |
| Number of normally open (NO) contacts | 1 |
| Max. short-time load | 100.0 |
| Maximum conductor cross-section | 2x2.5 кв.мм |
| Mech. endurance | 1.6x10^6 |
| Min making capacity at min voltage | 24.0 |
| Min. making capacity at min. current | 10.0 |
| Rated DC operating current DC-13 400 V | 0.63 |
| Rated operating current Ie at AC-15 400 V | 3.00 |
| Rated operating current Ie at AC-15 660 V | 1.50 |
| Rated insulation voltage Ui | В |
| Rated control supply voltage Us AC at 50 Hz from | 660/400/230 В |
| Rated control supply voltage Us DC from | 400/220 В |
| Rated operational current Ie at AC-15, 230V | 6 А |
| Rated operating current Ie at DC-13, 230 V | 1.5 А |
| Repairability | No |
| Switch-on current type | AC/DC |
| With built-in protection | No |
| Insulation resistance | 10.0 |
| IP protection rating | |
| Installation type | Direct connection |
| Contactor design | All KMI, KTI versions |
| Thermal resistance current | 10.0 |
| Width | 44.0 мм |
