Varton

LED Floodlight AirQub Sport 1120W 4000K 60deg. DALI dimmer VARTON V1-P1-703X5-04D07-65K1240

SKU: V1-P1-703X5-04D07-65K1240

ETIM: EC001744

482612 ₽

Preorder

Description Specifications Reviews

Without dimming	No
Supplied with lamp	Yes
Height/depth	721 мм
0-10 V dimming	No
1-10V dimming	No
DALI dimming	Yes
DMX dimming	No
Voltage modulation dimming	No
Length	580 мм
Protective surface coating	Powder-coated
Colour rendering index	80-89 (class 1B)
Electric shock protection class	I
Number of poles	5
Power factor	.95
Maximum power	1120 Вт
Housing material	Aluminum
Diffuser/lampshade material	Transparent plastic
Matt surface	No
Rated voltage up to	230 В
Rated voltage from	220 В
Rated luminous flux	158500 лм
Rated LED DC current from	656 мА
Colour uniformity (MacAdam ellipse)	SDCM5
Reflector	No (without)
Ballast included	Yes
Suitable for ceiling fastening	Yes
Suitable for wall mounting	Yes
Suitable for surface mounting	Yes
Suitable for suspended mounting	No
Suitable for monitor workplace EN 12464-1	No
Suitable for number of light sources	1
Suitable for low-voltage busbar trunking	No
Designed for flush mounting	No
Programmable dimming	No
Current type	AC/DC
With motion sensor	No
With light sensor	No
Light output	Straight
Luminous flux from	158500 лм
Light distribution	Symmetrical
Touch dimming	No
Core cross-section	.75 кв.мм
Connectable conductor cross-section at	4 кв.мм
Connected conductor cross-section from	1 кв.мм
Mounting method	Surface mounting
IP protection rating	IP67
Ambient temperature up to	40 град.C
Ambient temperature from	-40 град.C
Lamp type	Non-replaceable LED
Connection type	Terminating
Light beam angle	Wide beam 41-80 deg
Impact resistance	IK01
Control device	LED current-controlled device
Housing color	Grey
Light color	White
Colour temperature from	4000 К
Lamp base (holder)	No (without)
Width	676 мм
Luminaire efficiency	142 лм/Вт
