Varton
LED floodlight FL-Sport 130W 4000K 30deg. RAL7045 moire dimmer DALI VARTON V1-P1-70590-04D02-6513040
SKU: V1-P1-70590-04D02-6513040
ETIM: EC001744
43736 ₽
Preorder
FL-Sport is a series of floodlights for indoor and outdoor sports facilities and high-mast lighting. The housing is made of die-cast aluminum, and tempered glass is used to protect the optics. High light quality due to a color rendering index Ra>80. Convenient connection via an external wire with a connector. The floodlight is equipped with a swivel bracket for mounting on horizontal and vertical surfaces.
| Without dimming | No |
| Supplied with lamp | Yes |
| Height/depth | 90 мм |
| 0-10 V dimming | No |
| 1-10V dimming | No |
| DALI dimming | Yes |
| DMX dimming | No |
| Voltage modulation dimming | No |
| Length | 447 мм |
| Protective surface coating | Powder-coated |
| Colour rendering index | 80-89 (class 1B) |
| Electric shock protection class | It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly. |
| Number of poles | 5 |
| Power factor | .95 |
| Maximum power | 130 Вт |
| Housing material | Aluminum |
| Diffuser/lampshade material | Clear glass |
| Matt surface | No |
| Rated voltage up to | 230 В |
| Rated voltage from | 220 В |
| Rated luminous flux | 17200 лм |
| Rated LED DC current from | 542 мА |
| Colour uniformity (MacAdam ellipse) | SDCM5 |
| Reflector | No (without) |
| Ballast included | Yes |
| Suitable for ceiling fastening | Yes |
| Suitable for wall mounting | Yes |
| Suitable for surface mounting | Yes |
| Suitable for suspended mounting | No |
| Suitable for monitor workplace EN 12464-1 | No |
| Suitable for number of light sources | 1 |
| Suitable for low-voltage busbar trunking | No |
| Designed for flush mounting | No |
| Programmable dimming | No |
| Current type | AC/DC |
| With motion sensor | No |
| With light sensor | No |
| Light output | Straight |
| Luminous flux from | 17200 лм |
| Light distribution | Symmetrical |
| Touch dimming | No |
| Core cross-section | 1 кв.мм |
| Connected conductor cross-section from | 1 кв.мм |
| Mounting method | Surface mounting |
| Connection method | Screw terminal |
| IP protection rating | IP66 |
| Ambient temperature up to | 45 град.C |
| Ambient temperature from | -40 град.C |
| Lamp type | Non-replaceable LED |
| Connection type | Terminating |
| Light beam angle | Medium beam 20-40 deg. |
| Impact resistance | IK08 |
| Control device | LED current-controlled device |
| Housing color | Grey |
| Light color | White |
| Colour temperature from | 4000 К |
| Lamp base (holder) | No (without) |
| Width | 309 мм |
| Luminaire efficiency | 132 лм/Вт |
