LED floodlight FL-Sport 80deg. 170W 4000K RAL7045 muar VARTON V1-P1-70591-04L41-6517040
SKU: V1-P1-70591-04L41-6517040
ETIM: EC001744
47,580 ₽
Analogues by specifications
FL-Sport is a series of floodlights for indoor and outdoor sports facilities and high-mast lighting. The housing is made of die-cast aluminum, and tempered glass is used to protect the optics. High light quality due to a color rendering index Ra>80. Convenient connection via an external wire with a connector. The floodlight is equipped with a swivel bracket for mounting on horizontal and vertical surfaces.
Without dimming
Yes
Supplied with lamp
Yes
Height/depth
95 мм
0-10 V dimming
No
1-10V dimming
No
DALI dimming
No
DMX dimming
No
Voltage modulation dimming
No
Length
507 мм
Protective surface coating
Powder-coated
Colour rendering index
80-89 (class 1B)
Electric shock protection class
It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly.
Number of poles
3
Power factor
.95
Maximum power
170 Вт
Housing material
Aluminum
Diffuser/lampshade material
Clear glass
Matt surface
No
Rated voltage up to
230 В
Rated voltage from
220 В
Rated luminous flux
23000 лм
Rated LED DC current from
398 мА
Colour uniformity (MacAdam ellipse)
SDCM5
Reflector
No (without)
Ballast included
Yes
Suitable for ceiling fastening
Yes
Suitable for wall mounting
Yes
Suitable for surface mounting
Yes
Suitable for suspended mounting
No
Suitable for monitor workplace EN 12464-1
No
Suitable for number of light sources
1
Suitable for low-voltage busbar trunking
No
Designed for flush mounting
No
Programmable dimming
No
Current type
AC/DC
With motion sensor
No
With light sensor
No
Light output
Straight
Luminous flux from
23000 лм
Light distribution
Symmetrical
Touch dimming
No
Core cross-section
1 кв.мм
Connected conductor cross-section from
1 кв.мм
Mounting method
Surface mounting
Connection method
Screw terminal
IP protection rating
IP65
Ambient temperature up to
45 град.C
Ambient temperature from
-40 град.C
Lamp type
Non-replaceable LED
Connection type
Terminating
Light beam angle
Wide beam 41-80 deg
Impact resistance
IK08
Control device
LED current-controlled device
Housing color
Grey
Light color
White
Colour temperature from
4000 К
Lamp base (holder)
No (without)
Width
339 мм
Luminaire efficiency
135 лм/Вт
