Phase control relay ORF-10 3 phase 2 contacts 127-265V AC with neutral control ONI ORF-10-127-265VAC

SKU: ORF-10-127-265VAC

ETIM: EC001439

2642 ₽

Preorder

Description Specifications Reviews

Response time	0,1...10 мс
Height	90 мм
Height	90 мм
Hysteresis	2
Depth	64 мм
Voltage measuring range to	318 В
Voltage measuring range from	101 В
Voltage asymmetry setting range	5...15
Voltage setpoint range	2...20
Supply voltage frequency range	45...65
Voltage presence indicator	Green LED (Un)
Relay tripping indicator	Red LED (R)
Overvoltage category	3
Number of normally closed (NC) contacts	2
Number of normally open (NO) contacts	2
Number of changeover contacts
Number of switching contacts	2
Maximum permissible delay time	10 с
Maximum permissible trip delay time without holding	- с
Maximum cable cross-section	кв.мм
Mech. endurance	10^7
Minimum adjustable delay time	0 с
Minimum adjustable response delay time without time lag	.5 с
Supply voltage from	127...265 В
Rated voltage of contact assembly	250 AC / 24 DC
Rated current of contact groups at AC-1	8
Rated control supply voltage Us AC at 50 Hz up to	265 В
Rated control supply voltage Us AC at 50 Hz from	127 В
Rated control supply voltage Us DC from	- В
Measurement error	1
Operating position
Repairability	No
Switch-on current type	Alternating current (AC)
Monitored voltage current type	Alternating current (AC)
Mounting method	DIN rail (standard) 35 mm
Pollution degree	2
IP protection rating of terminal	IP20
Ingress protection (IP) of front panel	IP40
Operating temperature from	-20...55 град.C
Phase sequence monitoring function	Yes
Phase asymmetry detection function	Yes
Phase failure detection function	Yes
Overvoltage detection function	Yes
Undervoltage detection function	Yes
Width	36 мм
Electrical endurance	10^5
