Socket 1-way SP AtlasDesign 16A IP20 with ground protection shutters with cover mechanism mocha SE ATN000646 Systeme Electric
SKU: ATN000646
ETIM: EC000125
549 ₽
Price list (incl. VAT):
549 ₽
Available August 3
Availability
| Warehouse | Qty | Unit | Ready for pickup | Delivery to Smolensk | |
|---|---|---|---|---|---|
|
Remote warehouse
Available
|
20 | шт | August 3 | August 3 |
Select a warehouse to order
Systeme Electric (formerly Schneider Electric) AtlasDesign series mechanism in mocha color, single socket with grounding, shutters, and cover, suitable for 250 V networks, for 16 A current. The grounding contact provides additional protection against electric shock. With grounding present, the electrical potential goes into the ground, protecting the person. Faceplates are made of high-quality ABS plastic, resistant to scratches and UV radiation. Reinforced straight mounting lugs for better fixation of the mechanism in the mounting box.
| Special power supply | No special power supply required |
| RAL number (similar) | 7039 |
| Antibacterial | No |
| Supplied with plug (connector) | No |
| Material type/grade | Thermoplastic |
| Phase selection | No (without) |
| Device height | 71 мм |
| Device depth | 43 мм |
| Differential current protection | No |
| For heavy duty (per VDE) | No |
| Contact protection | Yes |
| Overvoltage protection | No |
| Protective surface coating | Untreated |
| Round protective grounding contact (pin) | Yes |
| Insulated installation | Yes |
| Design | With SCHUKO earthing contact |
| Number of active contacts (round) | 0 |
| Number of active contacts (flat) | 0 |
| Number of seats | 1 |
| Number of modules (modular system) | 0 |
| Number of switchable outlets | 0 |
| Number of phases | 1 |
| Material | Plastic |
| Extraction mechanism | No |
| Minimum depth of recessed mounting box | 43 мм |
| Halogen-free | Yes |
| Rated voltage | 250 В |
| Rated current | 16 А |
| Labelling surface | No |
| Suitable for ingress protection IP | IP20 |
| Transparent | No |
| With built-in USB charger | No |
| With power switch | No |
| With lock | No |
| With orientation lighting | No |
| With hinged cover | Yes |
| With illumination (mains voltage indication) | No |
| With signal lamp | No |
| With low-current fuse | No |
| With through-channel function | No |
| With central insert | No |
| Symbols/indication | Without marking |
| With shutters (touch protection) | Yes |
| Mounting method | Flush-mounted |
| Connection method | Screw terminal |
| Fastening type | Clamp mounting/Screw mounting |
| Surface type | Matte |
| Impact resistance | IK03 |
| Color | Brown |
| Frequency at | 50 Гц |
| Frequency from | 50 Гц |
| Device width | 71 мм |
