FEREKS
Luminaire DVO 02-22-830-D90 FEREKS 2000000084046
SKU: 2000000084046
ETIM: EC002892
5490 ₽
Price list (incl. VAT):
5490 ₽
Preorder
Модификация ДВО 02-22 предназначена для офисного освещения, освещения холлов, кассовых зон, торговых павильонов и других общественных и административных помещений.
| Without dimming | Yes |
| Supplied with lamp | Yes |
| Outer diameter | 200 мм |
| Height/depth | 95 мм |
| Operating voltage range | 176...264 |
| 0-10 V dimming | No |
| 1-10V dimming | No |
| DALI dimming | No |
| DMX dimming | No |
| Voltage modulation dimming | No |
| Length | 235.0 мм |
| Length | 235 мм |
| Power cable length | 0,4 м |
| Protective surface coating | Matte |
| Colour rendering index | 80-89 (class 1B) |
| Design | Downlight luminaire |
| Grille design | No (without) |
| Electric shock protection class | I |
| Fire hazard class | No |
| Climatic version | UKhL3.1 |
| Power factor | ≥ 0,96 |
| Maximum power | 22 Вт |
| Housing material | Aluminum |
| Housing material | Aluminum |
| Diffuser/lampshade material | PMMA (polymethyl methacrylate) |
| Grille material | No (without) |
| Matt surface | Yes |
| Mounting diameter | 200 мм |
| Lamp power | 22 Вт |
| Rated power | 22 кВт |
| Rated voltage up to | 230 В |
| Rated voltage from | 230 В |
| Rated luminous flux | 2081 лм |
| Reflector | No (without) |
| Ballast included | No |
| Perforated grille | No |
| Perforated reflector | No |
| Suitable for clamp mounting | No |
| Suitable for ceiling fastening | No |
| Suitable for lamp power from | 22 Вт |
| Suitable for pedestal/floor mounting | No |
| Suitable for wall mounting | Yes |
| Suitable for crossbeam mounting | Yes |
| Suitable for mounting on lighting busbar (track) | No |
| Suitable for surface mounting | Yes |
| Suitable for suspended mounting | No |
| Suitable for monitor workplace EN 12464-1 | No |
| Suitable for number of light sources | 0 |
| Suitable for low-voltage busbar trunking | No |
| Designed for flush mounting | Yes |
| Programmable dimming | No |
| Adjustability | Not adjustable |
| Current type | Alternating current (AC) |
| With motion sensor | No |
| With light sensor | No |
| With mounting clip or bracket | No |
| With dimmer | No |
| Lamp luminous efficacy | 94 лм/Вт |
| Light output | Straight |
| Luminous flux | 2081 лм |
| Luminous flux to | 2081 лм |
| Luminous flux from | 2081 лм |
| Light distribution | Cosine |
| Touch dimming | No |
| Cross-section of connectable conductors | 1 |
| Contains ignitor | No |
| Special application | Architectural/facade lighting |
| Mounting method | Recessed |
| Connection method | Screw terminal |
| IP protection rating | IP20 |
| Product/component type | Floodlight |
| Lamp type | LED lamp |
| Lamp type | Non-replaceable LED |
| Surface type | Matte |
| Connection type | Terminating |
| Diffuser type | Opal |
| Opening angle | 90 |
| Light beam angle | 90 deg |
| Impact resistance | IK05 |
| Control device | LED driver (LED power supply) |
| Housing color | White |
| Coating colour | White |
| Light color | White |
| Color temperature at | 3000 К |
| Colour temperature from | 3000 К |
| Lamp base (holder) | No (without) |
| Frequency (Hz) | |
| Width | 235 мм |
| Installation width | 200 мм |
| Plug-in electrical connection system | No |
| Power supply energy efficiency (ballast, driver, transformer) | A2 BAT |
