FEREKS

LED luminaire FHB 08-90-840-F30 FEREKS 2000000062785

SKU: 2000000062785

ETIM: EC001744

31076 ₽

Preorder

Description Specifications Reviews

Without dimming	Yes
Supplied with lamp	Yes
Outer diameter	208 мм
Height/depth	220 мм
Operating voltage range	176...264
0-10 V dimming	No
1-10V dimming	No
DALI dimming	No
DMX dimming	No
Voltage modulation dimming	No
Length	130.0 мм
Length	130 мм
Power cable length	0,4 м
Protective surface coating	Matte
Protective glass	Tempered, heat-resistant
Colour rendering index	80-89 (class 1B)
Design	Directional luminaire/spot
Grille design	No (without)
Electric shock protection class	I
Fire hazard class	No
Climatic version
Power factor	≥ 0,96
Maximum power	90 Вт
Housing material	Aluminum
Housing material	Aluminum
Diffuser/lampshade material	Tempered glass
Grille material	No (without)
Matt surface	Yes
Mounting diameter	11 мм
Lamp power	90 Вт
Rated power	90 кВт
Rated voltage up to	230 В
Rated voltage from	230 В
Rated luminous flux	11970 лм
Reflector	No (without)
Ballast included	No
Perforated grille	No
Perforated reflector	No
Suitable for clamp mounting	No
Suitable for ceiling fastening	Yes
Suitable for lamp power from	90 Вт
Suitable for pedestal/floor mounting	No
Suitable for wall mounting	Yes
Suitable for crossbeam mounting	Yes
Suitable for mounting on lighting busbar (track)	No
Suitable for surface mounting	Yes
Suitable for suspended mounting	No
Suitable for monitor workplace EN 12464-1	No
Suitable for number of light sources	0
Designed for flush mounting	No
Programmable dimming	No
Adjustability	Rotary
Current type	Alternating current (AC)
With motion sensor	No
With light sensor	No
With mounting clip or bracket	Yes
With dimmer	No
Lamp luminous efficacy	133 лм/Вт
Light output	Straight
Luminous flux	11970 лм
Luminous flux to	11970 лм
Luminous flux from	11970 лм
Light distribution	Concentrated
Touch dimming	No
Cross-section of connectable conductors	1
Contains ignitor	No
Special application	Other
Mounting method	Wall-mounted
Connection method	Screw terminal
IP protection rating	IP66
Product/component type	Floodlight
Lamp type	LED lamp
Lamp type	Non-replaceable LED
Surface type	Matte
Connection type	Terminating
Diffuser type	Soda-lime glass
Opening angle	30
Light beam angle	30 deg.
Impact resistance	IK08
Control device	LED driver (LED power supply)
Housing color	Grey
Coating colour	Grey
Light color	White
Color temperature at	4000 К
Colour temperature from	4000 К
Lamp base (holder)	No (without)
Frequency (Hz)
Width	207 мм
Installation width	100 мм
Plug-in electrical connection system	No
Power supply energy efficiency (ballast, driver, transformer)	A2 BAT
