80 162 NSF-PW7-120-5K-LED LED luminaire 120W 5000K IP65 18575lm outdoor Navigator 80162
SKU: 80162
ETIM: EC000062
14,386 ₽
Analogues by specifications
Stock by warehouse
Navigator NSF-PW7-LED series LED street lights are an energy-efficient replacement for traditional GKU, RKU, and ZhKU luminaires. Designed for outdoor lighting of facilities such as: medium and low-intensity traffic roads, parks and walkways, driveways, squares, parking lots, etc. The luminaires are developed using LCT technology, which increases the efficiency and service life of LEDs and minimizes luminous flux depreciation over the service life.
* High efficiency up to 160 lm/W
* Full-size housing made of corrosion-resistant alloy with increased aluminum and silicon content (Al 86%; Si 12%)
* Lenses integrated into the diffuser provide a semi-wide beam distribution
* Tilt angle adjustment: ±15°
* Two mounting methods: on inclined or vertical poles
* Ripple factor less than 5%.
Supplied with lamp
Yes
Diffuser material type/grade
Polycarbonate (PC)
Height/depth
83 мм
Diameter
59.4 мм
Length
510 мм
Ignitor
Not required
Colour rendering index
80-89 (class 1B)
Electric shock protection class
It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly.
Built-in luminaire energy efficiency class
A+
Number of LEDs
184
Power factor
.95
Maximum power
120 Вт
Maximum lamp power
120 Вт
Housing material
Aluminum
Diffuser/lampshade material
Opal plastic
Rated voltage up to
264 В
Rated voltage from
176 В
Rated luminous flux
18575 лм
Ballast included
Yes
Suitable for lamp power to
120 Вт
Suitable for lamp power from
120 Вт
Suitable for upper cut size to
52 мм
Suitable for top-cut size from
48 мм
Suitable for number of light sources
1
Adjustable optics
No
Current type
Alternating current (AC)
Luminous flux
18575 лм
Mounting method
Cantilever
Average rated service life
50000 ч
IP protection rating
IP65
Ambient temperature up to
50 град.C
Ambient temperature from
-60 град.C
Lamp type
LED
Impact resistance
IK08
Control device
LED driver (LED power supply)
Housing color
Grey
Color temperature at
5000 К
Colour temperature from
5000 К
Lamp base (holder)
No (without)
Width
281 мм
Luminaire efficiency
155 лм/Вт
