FLEX 50 50x52 5W 3000K 40deg. IP20 built-in DALI dimmer modular LED luminaire VARTON V1-R0-00435-10D45-2000530
SKU: V1-R0-00435-10D45-2000530
ETIM: EC001744
5718 ₽
Preorder
The FLEX 50 modular luminaire series is primarily designed for lighting in the hospitality sector (HORECA). The design of the interchangeable frames takes into account the specifics of use in various rooms. Swivel and fixed frames are available with different rotation radii and degrees of LED module recess relative to the outer surface of the frame. The deepest versions are suitable for rooms requiring soft and dimmed light.
| Without dimming | No |
| Supplied with lamp | Yes |
| Outer diameter | 50 мм |
| Built-in height/depth | 52 мм |
| Height/depth | 52 мм |
| 0-10 V dimming | No |
| 1-10V dimming | No |
| DALI dimming | Yes |
| DMX dimming | No |
| Voltage modulation dimming | No |
| Length | 50 мм |
| Protective surface coating | Powder-coated |
| Colour rendering index | 80-89 (class 1B) |
| Electric shock protection class | Please provide the text you would like me to translate. I am ready to translate your product data from Russian to English following all your specified rules. |
| Number of poles | 5 |
| Power factor | It appears your message contains only ".9". Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly. |
| Maximum power | 5 Вт |
| Housing material | Aluminum |
| Diffuser/lampshade material | Transparent plastic |
| Matt surface | No |
| Mounting diameter | 50 мм |
| Rated voltage up to | 230 В |
| Rated voltage from | 220 В |
| Rated luminous flux | 550 лм |
| Rated LED DC current from | 0 мА |
| Colour uniformity (MacAdam ellipse) | SDCM5 |
| Reflector | No (without) |
| Ballast included | Yes |
| Suitable for ceiling fastening | Yes |
| Suitable for wall mounting | No |
| Suitable for surface mounting | No |
| Suitable for suspended mounting | No |
| Suitable for monitor workplace EN 12464-1 | Yes |
| Suitable for number of light sources | 1 |
| Suitable for low-voltage busbar trunking | No |
| Designed for flush mounting | Yes |
| Programmable dimming | No |
| Current type | Alternating current (AC) |
| With motion sensor | No |
| With light sensor | No |
| Light output | Straight |
| Luminous flux from | 550 лм |
| Light distribution | Symmetrical |
| Touch dimming | No |
| Core cross-section | 1.5 кв.мм |
| Connectable conductor cross-section at | 1.5 кв.мм |
| Connected conductor cross-section from | 1.5 кв.мм |
| Mounting method | Recessed |
| Connection method | Clamp contact |
| IP protection rating | IP20 |
| Ambient temperature up to | 40 град.C |
| Ambient temperature from | 1 град.C |
| Lamp type | Non-replaceable LED |
| Connection type | Terminating |
| Light beam angle | Medium beam 20-40 deg. |
| Impact resistance | IK01 |
| Control device | LED current-controlled device |
| Housing color | Black |
| Light color | White |
| Color temperature at | 3000 К |
| Colour temperature from | 3000 К |
| Lamp base (holder) | No (without) |
| Width | 50 мм |
| Luminaire efficiency | 110 лм/Вт |
