LED luminaire Orex 30W 5000K M diffuser opal polycarbonate dimmer DALI VARTON V1-I1-70315-03OPD-6603050
SKU: V1-I1-70315-03OPD-6603050
ETIM: EC002892
9505 ₽
Preorder
No description available
| Without dimming | No |
| Supplied with lamp | Yes |
| Can be covered with thermal insulation | No |
| Height/depth | 229 мм |
| 0-10 V dimming | No |
| 1-10V dimming | No |
| DALI dimming | Yes |
| DMX dimming | No |
| GPRS dimming | No |
| LineSwitch dimming | No |
| RF dimming | No |
| Zigbee dimming | No |
| Dimming depending on control mechanism | No |
| Voltage modulation dimming | No |
| Push-button dimming | No |
| Trailing-edge phase dimming | No |
| Leading-edge phase-cut dimming | No |
| Length | 172 мм |
| Colour rendering index | 80-89 (class 1B) |
| Grille design | No (without) |
| Glow-wire test in accordance with IEC 60695-2-11 | 650 °C - 30 sec |
| Electric shock protection class | I |
| Built-in luminaire energy efficiency class | A++, A+, A (LED) |
| Number of poles | 5 |
| Power factor | .95 |
| Maximum power | 30 Вт |
| Housing material | Aluminum |
| Diffuser/lampshade material | Opal plastic |
| Rated voltage up to | 230 В |
| Rated voltage from | 220 В |
| Rated luminous flux | 3960 лм |
| Rated LED DC current from | 63 мА |
| Ballast included | Yes |
| Suitable for ceiling fastening | Yes |
| Suitable for wall mounting | Yes |
| Suitable for continuous light lines | No |
| Suitable for surface mounting | Yes |
| Suitable for suspended mounting | Yes |
| Suitable for monitor workplace EN 12464-1 | No |
| Suitable for number of light sources | 1 |
| Suitable for emergency lighting | No |
| Dimming potentiometer (built-in) | No |
| Designed for flush mounting | No |
| Programmable dimming | No |
| Fire protection "d" | No |
| Light distributor | Diffuser lens/optics/panel |
| DSI dimming | No |
| Current type | AC/DC |
| With motion sensor | No |
| With light sensor | No |
| With air circulation opening | No |
| Light output | Straight |
| Light distribution | Symmetrical |
| Touch dimming | No |
| Core cross-section | 1 кв.мм |
| Sinusoidal dimming | No |
| Manufacturer's proprietary dimming system | No |
| Connection method | Pluggable terminal |
| IP protection rating | IP66 |
| Ambient temperature up to | 45 град.C |
| Ambient temperature from | -40 град.C |
| Lamp type | Non-replaceable LED |
| Connection type | Terminating |
| Light beam angle | Extra wide beam > 80 deg |
| Impact resistance | IK10 |
| Control device | LED current-controlled device |
| Housing color | Grey |
| Light color | White |
| Colour temperature from | 5000 К |
| Lamp base (holder) | No (without) |
| Width | 172 мм |
| Luminaire efficiency | 132 лм/Вт |
