Varton
LED ceiling luminaire Ecophon Focus Dg 1200x600x57 50W 4000K IP40 opal diffuser with uniform illumination VARTON V1-A2-00620-10HG0-4005040
SKU: V1-A2-00620-10HG0-4005040
ETIM: EC002892
26977 ₽
Preorder
LED luminaire is compatible with Ecophon ceilings and is an energy-efficient replacement for fluorescent lamps. The housing is made of sheet steel with a white powder coating. The luminaire is equipped with an opal diffuser. Thanks to the uniform illumination of the optical part, the luminaire creates soft and comfortable lighting for the eyes in the room.
| Without dimming | Yes |
| Supplied with lamp | Yes |
| Can be covered with thermal insulation | No |
| Built-in length | 1200 мм |
| Built-in height/depth | 57 мм |
| Height/depth | 57 мм |
| 0-10 V dimming | No |
| 1-10V dimming | No |
| DALI dimming | No |
| DMX dimming | No |
| GPRS dimming | No |
| LineSwitch dimming | No |
| RF dimming | No |
| Zigbee dimming | No |
| Dimming depending on control mechanism | No |
| Voltage modulation dimming | No |
| Push-button dimming | No |
| Trailing-edge phase dimming | No |
| Leading-edge phase-cut dimming | No |
| Length | 1200 мм |
| Colour rendering index | 80-89 (class 1B) |
| Grille design | No (without) |
| Glow-wire test in accordance with IEC 60695-2-11 | No (without) |
| Electric shock protection class | It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly. |
| Built-in luminaire energy efficiency class | A++, A+, A (LED) |
| Number of poles | 3 |
| Power factor | .95 |
| Maximum power | 50 Вт |
| Housing material | Steel |
| Diffuser/lampshade material | Opal plastic |
| Rated voltage up to | 230 В |
| Rated voltage from | 220 В |
| Rated luminous flux | 5760 лм |
| Rated LED DC current from | 28 мА |
| Ballast included | Yes |
| Suitable for ceiling fastening | Yes |
| Suitable for wall mounting | No |
| Suitable for continuous light lines | No |
| Suitable for surface mounting | No |
| Suitable for suspended mounting | No |
| Suitable for monitor workplace EN 12464-1 | Yes |
| Suitable for number of light sources | 1 |
| Suitable for emergency lighting | No |
| Dimming potentiometer (built-in) | No |
| Designed for flush mounting | Yes |
| Programmable dimming | No |
| Fire protection "d" | No |
| Light distributor | Diffuser lens/optics/panel |
| DSI dimming | No |
| Current type | Alternating current (AC) |
| With motion sensor | No |
| With light sensor | No |
| With air circulation opening | No |
| Light output | Straight |
| Light distribution | Symmetrical |
| Touch dimming | No |
| Core cross-section | 2.5 кв.мм |
| Sinusoidal dimming | No |
| Manufacturer's proprietary dimming system | No |
| Connection method | Clamp contact |
| IP protection rating | IP40 |
| Ambient temperature up to | 40 град.C |
| Ambient temperature from | 1 град.C |
| Lamp type | Non-replaceable LED |
| Connection type | Terminating |
| Light beam angle | Extra wide beam > 80 deg |
| Impact resistance | IK02 |
| Control device | LED current-controlled device |
| Housing color | White |
| Light color | White |
| Color temperature at | 4000 К |
| Colour temperature from | 4000 К |
| Lamp base (holder) | No (without) |
| Width | 600 мм |
| Installation width | 600 мм |
| Luminaire efficiency | 115 лм/Вт |
