Varton
LED luminaire Olymp 2.0 GL 100W 5000K IP65 30deg. industrial diffused tempered glass VARTON V1-I0-70632-04L02-6510050
SKU: V1-I0-70632-04L02-6510050
ETIM: EC001744
40836 ₽
Preorder
Olymp 2.0 GL is a new generation of universal industrial luminaires with tempered glass. The luminaires are designed for installation in industrial and wet premises, warehouse complexes, as well as in P-IIa hazardous zones. Olymp 2.0 GL is resistant to aggressive environments, which expands its scope of application. The high luminous efficacy of the luminaire and a wide selection of optics make it an ideal solution for almost any lighting scenario. The luminaire is mounted on walls, ceilings, and floors with the possibility of adjusting the tilt angle within 180deg.
| Without dimming | Yes |
| Supplied with lamp | Yes |
| Height/depth | 170 мм |
| 0-10 V dimming | No |
| 1-10V dimming | No |
| DALI dimming | No |
| DMX dimming | No |
| Voltage modulation dimming | No |
| Length | 360 мм |
| Protective surface coating | Matte |
| Colour rendering index | 70-79 (class 2A) |
| Electric shock protection class | It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly. |
| Number of poles | 3 |
| Power factor | .95 |
| Maximum power | 100 Вт |
| Housing material | Aluminum |
| Diffuser/lampshade material | Clear glass |
| Matt surface | No |
| Lamp power | 100 Вт |
| Rated voltage up to | 230 В |
| Rated voltage from | 220 В |
| Rated luminous flux | 14500 лм |
| Rated LED DC current from | 625 мА |
| Colour uniformity (MacAdam ellipse) | SDCM5 |
| Reflector | No (without) |
| Ballast included | Yes |
| Perforated grille | No |
| Perforated reflector | No |
| Suitable for ceiling fastening | Yes |
| Suitable for wall mounting | Yes |
| Suitable for surface mounting | Yes |
| Suitable for suspended mounting | No |
| Suitable for monitor workplace EN 12464-1 | No |
| Suitable for number of light sources | 1 |
| Suitable for low-voltage busbar trunking | No |
| Designed for flush mounting | No |
| Programmable dimming | No |
| Current type | AC/DC |
| With motion sensor | No |
| With light sensor | No |
| With dimmer | No |
| Light output | Straight |
| Luminous flux from | 14500 лм |
| Light distribution | Symmetrical |
| Touch dimming | No |
| Core cross-section | 1 кв.мм |
| Connectable conductor cross-section at | 1 кв.мм |
| Connected conductor cross-section from | 1 кв.мм |
| Contains ignitor | No |
| Mounting method | Surface mounting |
| IP protection rating | IP65 |
| Ambient temperature up to | 45 град.C |
| Ambient temperature from | -40 град.C |
| Lamp type | Non-replaceable LED |
| Surface type | Matte |
| Connection type | Terminating |
| Light beam angle | Medium beam 20-40 deg. |
| Impact resistance | IK08 |
| Control device | LED current-controlled device |
| Housing color | Aluminum |
| Coating colour | No (without) |
| Light color | White |
| Color temperature at | 5000 К |
| Colour temperature from | 5000 К |
| Lamp base (holder) | No (without) |
| Width | 183 мм |
| Plug-in electrical connection system | No |
| Luminaire efficiency | 145 лм/Вт |
