Контактор (группа IEK)
Automatic circuit breaker 3p 1000A 33.5kA VA55-41 371870-00 UHL3 690V Contactor 1024205 Contactor (IEK group)
SKU: 1024205
ETIM: EC000228
324730 ₽
Preorder
Switches are designed for operation in electrical installations with a voltage of up to 660 V AC at 50 and 60 Hz and up to 440 V DC for infrequent switching and disconnecting of electrical circuits, as well as for protecting electrical equipment from overloads and short circuits.
VA52-41 – current-limiting (application category A), with electromagnetic releases.
VA53-41 - current-limiting (application category A), with electromagnetic and electronic releases.
VA55-41 – selective (application category B), with electronic releases.
VA56-41 – without maximum current releases.
| Built-in ground fault protection | No |
| Overload protection device setting range to | 1000 А |
| Setting range of overload protection device from | 300 А |
| Instantaneous short-circuit release setting range to | 16000 А |
| Instantaneous short-circuit release setting range from | 4000 А |
| Number of auxiliary NO contacts | 3 |
| Number of auxiliary break contacts | 3 |
| Number of poles | 3 |
| Design | Built-in withdrawable device |
| Motor drive optional | No |
| Rated ultimate short-circuit breaking capacity Icu at 400 V, 50 Hz | 55 кА |
| Rated voltage up to | 690 В |
| Rated voltage from | 0 В |
| Rated current | 1000 А |
| Rated continuous current Iu | 1000 А |
| Suitable for DIN-rail mounting | No |
| With minimum voltage protection | Yes |
| IP protection rating | IP00 |
