Residual Current Circuit Breaker (RCCB) 2p (1P+N) 32A 100mA type AC 6kA PRIZMA TOKOV ELECTRIC TKE-PZ60-RCDM-2-32-100-AC

SKU: TKE-PZ60-RCDM-2-32-100-AC

ETIM: EC000003

1778 ₽

Price list (incl. VAT): 1778 ₽

Available July 30

	Warehouse	Qty	Unit	Ready for pickup	Delivery to Смоленск
	Удалённый склад	5	шт	July 30	July 30

Select a warehouse to order

Description Specifications Reviews

Additional equipment possible	No
Mounting installation depth	50 мм
Number of poles	2
Rated ultimate breaking capacity (Icw)	6 кА
Rated impulse voltage	6 кВ
Rated voltage	230 В
Rated insulation voltage Ui	400 В
Rated current	32 А
Rated leakage current	100 мА
Ambient operating temperature to	50 град.C
Ambient operating temperature from	-25 град.C
With short-time delayed tripping	No
With interlock device	No
Selective protection	No
Flexible stranded conductor cross-section up to	10 кв.мм
Stranded flexible conductor cross-section from	1 кв.мм
Solid conductor cross-section to	16 кв.мм
Solid conductor cross-section from	1 кв.мм
Mounting method	DIN rail
IP protection rating	IP20
Residual current type	Alternating current (AC)
Frequency (Hz)	50 Hz
Width in modular units	2
