Limit switch 1NO1NC miniature hinged type with short lever and long handle DEKraft 34031DEK
SKU: 34031DEK
ETIM: EC000030
554 ₽
Preorder
Miniature limit switch with 1NO1NC contact group, hinge type with short lever and long actuator; features a thermoplastic double-insulated housing, modular design for easy maintenance, and a compact shape (in accordance with DIN EN 50047-2020). IP65 and IK04 protection ratings ensure impact resistance, making it ideal for intensive use in heavy-duty operating conditions. The switch is mounted to equipment using metric or self-tapping mounting screws and has an electrical endurance of at least 500,000 cycles in category DC-13; it complies with GOST IEC 60947.-5-1, GOST IEC 60204-1 standards.
| Without self-return (with latching) | No |
| Interface version | No (without) |
| Gas explosion protection category (EU ATEX directives) | No (without) |
| Dust explosion protection category (EU ATEX Directive) | No (without) |
| Number of normally closed (NC) contacts | 1 |
| Number of normally open (NO) contacts | 1 |
| Number of switching contacts | 2 |
| Housing material | Plastic |
| Rated operational current Ie at AC-15, 230V | It appears your message contains only ".8". Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly. А |
| Suitable for security systems | Yes |
| Ambient operating temperature to | 80 град.C |
| Ambient operating temperature from | -20 град.C |
| IP protection rating | IP65 |
| Connection type | PG cable gland |
| Control element type | Roller lever |
