GM2P 0.63-1.0A motor protection circuit breaker combined trip rotary handle SE GM2P05 Systeme Electric
SKU: GM2P05
ETIM: EC000074
9370 ₽
Preorder
SystemePact GM2P series circuit breaker with combined trip unit, adjustable in the range 0.63 - 1.0 A, with rotary handle. SystemePact GM2P series circuit breakers are designed for controlling and protecting electric motors from overload and short circuit in industrial, infrastructure, and construction facilities; installed on DIN rail or on a mounting plate using screws (formerly Schneider Electric TeSys GV2 - Circuit Breaker <32A, GV2 GV2P05, GV2RT05, GV2P05).
| Height | 90 мм |
| Depth | 89.5 мм |
| Overload protection device setting range to | 1 А |
| Setting range of overload protection device from | .63 А |
| Number of poles | 3 |
| Design | Built-in fixed-mounted device |
| Rated power at AC-3, 400 V | Please provide the text you would like me to translate. Currently, you have only provided ".25". кВт |
| Rated ultimate breaking capacity Icu at 400V AC | 100 кА |
| Rated voltage at | 690 В |
| Rated voltage from | 690 В |
| Rated continuous current Iu | 1 А |
| With overheating protection | Yes |
| Tripping system | Thermomagnetic |
| With built-in auxiliary switch | No |
| With built-in undervoltage release | No |
| IP protection rating | IP20 |
| Main electrical circuit connection type | Screw connection |
| Control element type | Rotary switch |
| Phase failure sensitive | Yes |
| Width | 45 мм |
